Power Supply|CHIEFTEC|700 Watts|Efficiency 80 PLUS BRONZE|PFC Active|TPS-700S

Stock: 50
Model: TPS-700S
Weight: 2.11kg
Dimensions: 240.00 x 0.00 x 109.00
UPC: 075326307650
JAN: 0753263076502
MPN: TPS-700S

53.07€

Ex Tax: 43.86€

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

ATX 2.3 | 700 Watts | Cooling System 12cm fan | 80 PLUS BRONZE | PFC Active

Certificates
Certification	ErP, CE, CB, EAC, TUV
Compliance certificates	RoHS
Ports & interfaces
EPS power connector (4+4 pin)	Yes
Motherboard power cable length	65 cm
Peripheral (Molex) power cable length	150,500 mm
Motherboard power connector	20+4 pin ATX
SATA power cable length	150,500 mm
Number of SATA power connectors	6
Peripheral (Molex) power connectors (4-pin)	3
PCI Express power cable length	50 cm
PCI Express power connectors (6+2 pin)	2
ATX power connector (20+4 pin)	Yes
Cabling type	Non-Modular
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	87 mm
Weight	1.74 kg
Design
Fan diameter	12 cm
Number of fans	1 fan(s)
Product colour	Black
Packaging data
Package weight	2.15 kg
Package type	Box
Performance
Power supply unit (PSU) form factor	ATX
Supported motherboard form factors	ATX
80 PLUS certification	80 PLUS Bronze
Purpose	PC
Power
Total power	700 W
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+12V)	648 W
Max output current (+12V)	54 A
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	19 A
Max output current (+5V)	17 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over voltage, Overheating, Overload, Short circuit, Under voltage
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Input current	10 A
Logistics data
Harmonized System (HS) code	84733020
Other features
EPS cable length	65 cm
