DST-Pro USB4, USB-C Laptop Docking Station
DST-Pro USB4, USB-C Laptop Docking Station
240.80€
Ex Tax: 199.01€
- Stock: 3
- Model: 43372
- UPC: 400288843372
- JAN: 4002888433723
- MPN: 43372
The DST-Pro USB4 of the latest USB4 generation is a high performance, multifunctional solution for connecting laptops, tablets or mobile phones to a range of interfaces including an 8K 30Hz DisplayPort or HDMI display or two displays simultaneously at 4K 60Hz*, using a single cable. It also supports video resolutions of 4K 120Hz, making it the ideal tool for high resolution video editing or game streaming.
This docking station delivers a whole host of capable ports to connect your devices into your workflow. With SuperSpeed USB and Ethernet, you can expect to have a blazing fast experience and improve your productivity whilst the Card Readers (SD and Micro-SD) allow you to expand your storage capacity beyond that of your device. Through a single USB-C cable, connect to multiple SuperSpeed 10Gbps USB Type A or Type C ports, a 3.5mm combined headphone jack, Gigabit Ethernet, (Micro-) SD card slots, DisplayPort and HDMI.
The USB4 Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.
This USB4 Laptop Docking Station is compatible with computers featuring the USB Type C port with support for DisplayPort 1.4 Alternate Mode, i.e. USB4 or USB 3.2 as well as Thunderbolt 3 or TB4 host devices.
*Please note that macOS does not support MST.
This docking station delivers a whole host of capable ports to connect your devices into your workflow. With SuperSpeed USB and Ethernet, you can expect to have a blazing fast experience and improve your productivity whilst the Card Readers (SD and Micro-SD) allow you to expand your storage capacity beyond that of your device. Through a single USB-C cable, connect to multiple SuperSpeed 10Gbps USB Type A or Type C ports, a 3.5mm combined headphone jack, Gigabit Ethernet, (Micro-) SD card slots, DisplayPort and HDMI.
The USB4 Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.
This USB4 Laptop Docking Station is compatible with computers featuring the USB Type C port with support for DisplayPort 1.4 Alternate Mode, i.e. USB4 or USB 3.2 as well as Thunderbolt 3 or TB4 host devices.
*Please note that macOS does not support MST.
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Ports & interfaces | |
| Host interface | USB4 |
| DisplayPorts quantity | 1 |
| Microphone in | Yes |
| USB Power Delivery revision | 3.0 |
| USB4 ports quantity | 1 |
| Connectivity technology | Docking |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| USB 2.0 ports quantity | 3 |
| USB Power Delivery (USB PD) | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDCP | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.4 |
| HDCP version | 2.2 |
| PowerShare | Yes |
| Number of USB ports with PowerShare support | 3 |
| Combo headphone/mic port | Yes |
| Sustainability | |
| Sustainability compliance | Yes |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Weight & dimensions | |
| Width | 129 mm |
| Depth | 69.5 mm |
| Height | 48 mm |
| Weight | 300 g |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Packaging content | |
| Manual | Yes |
| Cables included | USB Type-C to USB Type-C |
| Packaging data | |
| Package width | 174 mm |
| Package depth | 151 mm |
| Package height | 56 mm |
| Package weight | 400 g |
| Performance | |
| Data transfer rate | 1 Gbit/s |
| Product colour | Anthracite |
| Card reader integrated | Yes |
| Housing material | Aluminium |
| Maximum refresh rate | 120 Hz |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Maximum digital resolution | 7680 x 4320 pixels |
| Number of displays supported | 2 |
| Power | |
| Power source type | USB |
| Power consumption (max) | 20 W |
