H330

Name: H330
Brand: DELL
Price: 332.02 EUR
Availability: InStock

H330

332.02€

Ex Tax: 274.40€

Stock: 1
Model: 405-AAFG
UPC: 539706398148
JAN: 5397063981489
MPN: 405-AAFG

DELL

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

The PERC 9 H330 RAID Controller from Dell offers reliability and performance in addition to providing management with the tolerant disk subsystem failures. This RAID controller offers expandable storage capacity to improve the performance of your server systems. The double module channel provides high-speed connectivity. This product has been tested and validated on Dell systems to ensure compatibility with your computer. It is supported by Dell Technical Support when used with a Dell system.

Operational conditions
Operating relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-45 - 105 °C
Operating temperature (T-T)	0 - 65 °C
Storage relative humidity (H-H)	5 - 90%
Ports & interfaces
Host interface	PCI Express x8
Supported storage drive interfaces	SAS, Serial ATA III
Internal mini-SAS ports	2
PCI Express slots version	3.0
Processor
Processor family	LSI
Processor model	SAS3008
Built-in processor	Yes
System requirements
Compatible operating systems	Microsoft Windows Server 2008 R2 SP1 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R1 & R2 Red Hat Enterprise Linux 5.8 Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 10 SP4 SUSE Linux Enterprise Server 11 SP3 VMware ESXi 5.1 VMware 6.0
Weight & dimensions
Width	64.4 mm
Depth	167.6 mm
Performance
Compatible products	PowerEdge FC630 PowerEdge M630P
Data transfer rate	12 Gbit/s
RAID levels	0, 1, 5, 10, 50
SSD support	Yes
LED indicators	Yes
RAID Level Migration	Yes
Number of devices supported	128
Online Capacity Expansion	Yes
S.M.A.R.T. support	Yes
Power
Voltage	12 V
Logistics data
Harmonized System (HS) code	84733080
Other features
Hot-Plug support	Yes
PCI Card form factor	Full-height (low-profile)

Tags: RAID Controllers
