AC750

AC750
AC750
AC750
AC750
AC750
AC750
AC750
AC750
AC750
27.66€
Ex Tax: 22.86€
  • Stock: 50
  • Model: ARCHERC20
  • UPC: 693536409160
  • JAN: 6935364091606
  • MPN: ARCHER C20
- Supports 802.11ac standard - the next generation of Wi-Fi
- Simultaneous 2.4GHz 300Mbps and 5GHz 433Mbps connections for 733Mbps of total available bandwidth
- 2 external antennas provide stable omnidirectional signal and superior wireless coverage
- USB port - share a printer locally and files & media with networked devices or remotely via FTP server

802.11ac - The Next Generation of Wi-Fi
TP-LINK’s Archer C20 comes with the next generation Wi-Fi standard – 802.11ac, backward compatible with 802.11n and 3 times faster than wireless N speeds. With higher power efficiency and robust security, 802.11ac is the perfect way to accelerate a home multimedia network and solve congestion that multiple devices may cause.

733Mbps Dual Band Connections for Lag-Free Work
With 433Mbps wireless speeds over the crystal clear 5GHz band and 300Mbps over the 2.4GHz band, Archer C20 offers you the flexibility of two dedicated networks and ensures amazing wireless performance. Simple tasks such as sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band – all at the same time.

Stable Omnidirectional Signal and Superior Coverage
With 2 fixed external antennas combined with higher quality antenna technology, you can experience excellent wireless performance with stable signal in every direction and high speed across greater distances. This provides you with incredible wireless coverage and reliability from anywhere in your large home or office.

Easy USB Storage and Sharing
With the USB port, you can share a printer locally and files & media with networked devices or remotely via FTP server.
Antenna
Antenna design External
Antennas quantity 3
Transmit power 23 dBmW
Certificates
Compliance certificates RoHS, Federal Communications Commission (FCC), CE
Features
Built-in processor Yes
Processor cores 1
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Storage relative humidity (H-H) 5 - 90%
Ports & interfaces
USB port No
Ethernet LAN (RJ-45) ports 4
DC-in jack Yes
Sustainability
Sustainability compliance Yes
System requirements
Windows operating systems supported Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported Yes
Linux operating systems supported Yes
WAN connection
Ethernet WAN Yes
DSL WAN No
SIM card slot No
3G/4G USB modem compatibility No
WAN connection type RJ-45
Weight & dimensions
Width 230 mm
Depth 144 mm
Height 35 mm
Wireless LAN features
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max) 433 Mbit/s
Wi-Fi standards 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band) 300 Mbit/s
WLAN data transfer rate (second band) 433 Mbit/s
Design
On/off switch Yes
Product colour Black, White
LED indicators Yes
Product type Tabletop router
Management features
Web-based management Yes
WPS push button Yes
Quality of Service (QoS) support Yes
Reset button Yes
Network
Ethernet LAN Yes
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates 10,100 Mbit/s
Ethernet LAN interface type Fast Ethernet
Dynamic DNS (DDNS) Yes
VPN Passthrough Yes
Number of guest networks (2.4 GHz) 1
VPN support PPTP, L2TP, IPSec
Number of guest networks (5 GHz) 1
Cabling technology 10/100Base-T(X)
Security
Security algorithms WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Firewall Yes
Firewall security SPI
Filtering Yes
MAC address filtering Yes
IP address filtering Yes
Port-based Network Access Control (PNAC) Yes
Guest access Yes
Stateful Packet Inspection (SPI) Yes
DoS attack prevention Yes
DMZ support Yes
Packaging content
Cables included LAN (RJ-45)
AC adapter included Yes
Quick installation guide Yes
Packaging data
Package width 357 mm
Package depth 223 mm
Number of products included 1 pc(s)
Package height 68 mm
Package weight 670 g
Power
Power source type DC
Output voltage 9 V
Output current 0.6 A
Protocols
Supported network protocols IPv4, IPv6
Universal Plug and Play (UPnP) Yes
Other features
WLAN data transfer rates supported 300,433 Mbit/s
