BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point








BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
652.95€
Ex Tax: 539.63€
- Stock: 4
- Model: EAP783
- UPC: 084003071007
- JAN: 0840030710070
- MPN: EAP783
Multi-Link Operation (MLO)
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.△
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.△
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
Antenna | |
Antenna type | Internal |
Features | |
2.4 GHz | Yes |
Maximum data transfer rate | 19000 Mbit/s |
5 GHz | Yes |
6 GHz | Yes |
Ethernet LAN data rates | 10000 Mbit/s |
Frequency band | 2.4 - 6 GHz |
Maximum data transfer rate (2.4 GHz) | 1376 Mbit/s |
Maximum data transfer rate (5 GHz) | 5760 Mbit/s |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
Automatic channel selection | Yes |
Maximum data transfer rate (6 GHz) | 11520 Mbit/s |
MIMO | Yes |
MIMO type | Multi User MIMO |
Quality of Service (QoS) support | Yes |
VLAN support | Yes |
Number of users | 760 user(s) |
Automatic channel scanning | Yes |
Band steering | Yes |
Rate limiting | Yes |
Airtime Fairness (ATF) | Yes |
Flow control support | Yes |
BeamForming | Yes |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 90% |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
DC-in jack | Yes |
Weight & dimensions | |
Width | 280 mm |
Depth | 280 mm |
Height | 46.5 mm |
Design | |
Reset button | Yes |
Product colour | White |
LED indicators | Yes |
Placement | Ceiling, Wall |
Security | |
Security algorithms | WPA, WPA2, WPA3 |
Access Control List (ACL) | Yes |
Packaging content | |
Mounting kit | Yes |
Quantity per pack | 1 pc(s) |
Quick start guide | Yes |
Packaging data | |
Package type | Box |
Power | |
DC voltage range | 12 V |
Power over Ethernet (PoE) | Yes |
