NWA110AX

Name: NWA110AX
Brand: ZYXEL
Price: 186.87 EUR
Availability: InStock

NWA110AX

186.87€

Ex Tax: 154.44€

Stock: 15
Model: NWA110AX-EU0102F
UPC: 471893761025
JAN: 4718937610259
MPN: NWA110AX-EU0102F

ZYXEL

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

WiFi 6, Wait No More
NWA110AX The Best Deal of 11ax Access Point

True WiFi 6
The NWA110AX is truly the next generation of wireless (WiFi 6) AP for businesses looking for a most economical upgrade path to 11ax. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO which can’t be found in earlier releases of 802.11ax products.

Simpler upgrade path
The NWA110AX has been designed to be highly efficient in PoE budget, allowing for an easy upgrade path for those wishing to experience all that WiFi 6 has to offer without the need to upgrade existing PoE+ switches

Manage it your way!
As it comes with support for NebulaFlex, Zyxel’s scalable, cloud-based management system, the NWA110AX can be managed via NCC (Nebula control Center) or simply operate alone (controller less). You can choose the way that is best suited to your needs.

Antenna
Antenna gain level (max)	6 dBi
Antennas quantity	2
Antenna type	Internal
Antenna features	Integrated antenna
Polarization	Dual polarization
Certificates
Certification	FCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55022 EN55024 EN61000-3-2/-3 EN60601-1-2 BSMI CNS13438 Safety Safety EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Features
2.4 GHz	Yes
Maximum data transfer rate	1000 Mbit/s
5 GHz	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.412 - 2.472, 5.470 - 5.725 GHz
Maximum data transfer rate (2.4 GHz)	575 Mbit/s
Bandwidth	0.08 GHz
Maximum data transfer rate (5 GHz)	1200 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Receiver sensitivity	Min. Rx sensitivity up to -101 dBm
VLAN support	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Fast roaming	Yes
Automatic channel scanning	Yes
Band steering	Yes
Cabling technology	10/100/1000Base-T(X)
Transmitting power	22 dBmW
Virtual LAN features	SSID-based VLAN assignment
Operational conditions
Operating relative humidity (H-H)	10 - 95%
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	10 - 90%
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Weight & dimensions
Width	180 mm
Depth	180 mm
Height	39 mm
Weight	453 g
Design
WPS push button	Yes
Reset button	Yes
On/off switch	Yes
Product colour	White
LED indicators	Yes
Placement	Ceiling, Table, Wall
Management features
Web-based management	Yes
Command-line interface (CLI)	Yes
Security
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-Enterprise, WPA3
Packaging content
Mounting kit	Yes
AC adapter included	Yes
Quantity per pack	1 pc(s)
Quick start guide	Yes
Packaging data
Package width	229 mm
Package depth	216 mm
Package height	64 mm
Package weight	770 g
Power
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17 W
AC input voltage	5 - 12 V
Input current	1.5 A
Protocols
Routing protocols	IP
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)
Logistics data
Harmonized System (HS) code	85176990

Tags: Wireless Access Points
