XVR5104HS-I3




XVR5104HS-I3
115.58€
Ex Tax: 95.52€
- Stock: 8
- Model: DH-XVR5104HS-I3
- MPN: DH-XVR5104HS-I3
Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies,
WizSense provides intelligent, simple and inclusive products and solutions.
Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AI
upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.
WizSense provides intelligent, simple and inclusive products and solutions.
Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AI
upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -10 - 55 °C |
Ports & interfaces | |
Video input channels | 4 channels |
BNC input ports | 4 |
HDMI ports quantity | 1 |
VGA (D-Sub) output ports | 1 |
RS-485 ports | 1 |
USB 2.0 ports quantity | 2 |
Audio input | 1 RCA |
BNC output ports | 1 |
Audio output | 1 RCA |
Weight & dimensions | |
Width | 260 mm |
Depth | 237.9 mm |
Height | 47.6 mm |
Weight | 1 kg |
Hard drive | |
Number of HDDs supported | 1 |
HDD interface | SATA |
Maximum HDD capacity | 16 TB |
Network | |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Ethernet LAN (RJ-45) ports | 1 |
Supported network protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P |
Packaging data | |
Package width | 333 mm |
Package depth | 315 mm |
Package height | 89 mm |
Package weight | 1.4 kg |
Performance | |
Maximum video resolution | 1920 x 1080 pixels |
Playback resolutions supported | 1920 x 1080, 1280 x 1024, 1280 x 720 |
Maximum frame rate | 60 fps |
Product colour | Black |
Video capturing speed | 30 fps |
Video motion detection | Yes |
Certification | FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024 |
PTZ control | Yes |
Video loss detection | Yes |
Channels quantity | 4 channels |
Video streaming | Yes |
Dual stream support | Yes |
Rack capacity | 1U |
Audio formats supported | G.711 A-law, G.711 μ-law, PCM |
Operating system installed | Embedded LINUX |
Analog signal format system | NTSC, PAL |
Backup function | Yes |
Video compression formats | H.264, H.264+, H.265, H.265+ |
Audio system | 2-way |
Power | |
DC voltage | 12 V |
Power consumption (typical) | 4 W |
Power supply type | DC |
