NET VIDEO RECORDER 16CH 16POE/NVR4216-16P-EI DAHUA

Name: NET VIDEO RECORDER 16CH 16POE/NVR4216-16P-EI DAHUA
Brand: DAHUA
SKU: 1398027
Price: 467.93 EUR
Availability: InStock

NET VIDEO RECORDER 16CH 16POE/NVR4216-16P-EI DAHUA

467.93€

Ex Tax: 386.72€

Stock: 6
Model: NVR4216-16P-EI
UPC: 692317258579
JAN: 6923172585790
MPN: NVR4216-16P-EI

DAHUA

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

Channels 16 | Drives/bays 2 | Power supply requirements 100–240 VAC, 47-63 Hz | Dim. 375.0 mm × 329.3 mm x 53.0 mm | Temp. range –10 °C to +55 °C

Features
Rack capacity	1U
Rack mounting	Yes
Product colour	Black
Brand compatibility	Any brand
Operational conditions
Operating relative humidity (H-H)	10 - 93%
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 55 °C
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN data rates	10,100,1000 Mbit/s
Audio RCA inputs	1
HDMI ports quantity	1
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	16
VGA (D-Sub) output ports	1
HDMI output	Yes
Audio RCA outputs	1
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Networking standards	IEEE 802.3af, IEEE 802.3at
RS-232 interface	Yes
Supported network protocols	HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP
Internal SATA ports quantity	2
Processor
Processor cores	2
Built-in processor	Yes
System requirements
Mobile operating systems supported	Android, iOS
Weight & dimensions
Width	375 mm
Depth	329.3 mm
Height	53 mm
Weight	2.6 kg
Package width	451 mm
Package depth	425 mm
Package height	147 mm
Package weight	3.8 kg
Hard drive
Maximum storage capacity	16 TB
Number of HDDs supported	2
Performance
Alarm input channels	4
Alarm output channels	2
Supported resolutions	1920x1080, 1280x1024, 1280x720, 1024x768
Bit rate	8192 Kbit/s
Maximum resolution	1920 x 1080 pixels
Video motion detection	Yes
Video formats supported	H.264, M-JPEG
Two-way talk	Yes
Number of motion detection zones	396
PTZ control	Yes
Video loss detection	Yes
Recording modes	Manual, Schedule, Stop
Split screen	Yes
Playback controls	Yes
Recording time	120 min
Playback modes	Backup selection, Digital zoom, Forward, Full screen, Next camera, Pause, Play, Previous camera, Repeat, Reverse, Shuffle, Speed Adjust, Stop
Operating system installed	Embedded LINUX
Backup function	Yes
On Screen Display (OSD)	Yes
Video input channels	16 channels
Number of users	128 user(s)
Snapshot	Yes
Power
Total Power over Ethernet (PoE) budget	130 W
Power consumption (typical)	30 W
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power over Ethernet (PoE) power per port	25.5 W

Tags: Network Video Recorders (NVR)
