NVR2108-4KS3






NVR2108-4KS3
142.01€
Ex Tax: 117.36€
- Stock: 4
- Model: NVR2108-4KS3
- UPC: 692317250784
- JAN: 6923172507846
- MPN: NVR2108-4KS3
The NVR2000-4KS3 model of the Lite Series NVR is favored for its outstanding performance. It supports 4K resolution for scenes that require highly detailed images, and can serve as the edge, central, or backup storage with an intuitive shortcut menu for remote management and control. This NVR also features Smart Motion Detection (SMD) by recorder, which can distinguish target vehicles and humans from ordinary ones in real-time. This NVR is both costeffective and easy-to-install, making it ideal for a wide range of applications such as villas, shops and other small and medium-sized scenes.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and ilter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
Perimeter Protection by Camera
Automatically ilters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and ilter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
Perimeter Protection by Camera
Automatically ilters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.
Features | |
Rack capacity | 1U |
Certification | CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 |
Rack mounting | Yes |
Product colour | Black |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 93% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | -10 - 55 °C |
Ports & interfaces | |
Ethernet LAN data rates | 10,100 Mbit/s |
eSATA ports quantity | 1 |
Audio RCA inputs | 1 |
HDMI ports quantity | 1 |
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 8 |
VGA (D-Sub) output ports | 1 |
Audio RCA outputs | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Networking standards | IEEE 802.3af, IEEE 802.3at |
Supported network protocols | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration |
Processor | |
Built-in processor | Yes |
System requirements | |
Mobile operating systems supported | Android, iOS |
Browser supported | Chrome; IE; Safari; Edge; Firefox |
Weight & dimensions | |
Width | 260 mm |
Depth | 232.5 mm |
Height | 47.6 mm |
Weight | 890 g |
Package width | 374 mm |
Package depth | 119 mm |
Package height | 311 mm |
Package weight | 2.05 kg |
Wireless LAN features | |
Wi-Fi | No |
Hard drive | |
Maximum storage capacity | 20 TB |
HDD interface | SATA |
Performance | |
Video recording modes | 720p, 960p, 1080p |
Supported resolutions | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
Maximum resolution | 3840 x 2160 pixels |
Video motion detection | Yes |
Video formats supported | H.264, H.264+, H.265, H.265+ |
Input bandwidth | 80 Mbit/s |
Output bandwidth | 60 Mbit/s |
Audio formats supported | G.711 A-law, G.711 μ-law, G.726, PCM |
Operating system installed | Embedded LINUX |
Image formats supported | MJPEG |
Video input channels | 4 channels |
Power | |
Total Power over Ethernet (PoE) budget | 72 W |
Power consumption (typical) | 10 W |
Output voltage | 53 V |
Output current | 1.22 A |
Power consumption (max) | 25.5 W |
