HAC-HDW1231TMQ-A-0280B

Name: HAC-HDW1231TMQ-A-0280B
Brand: Dahua Technology
Price: 86.64 EUR
Availability: InStock

HAC-HDW1231TMQ-A-0280B

86.64€

Ex Tax: 71.60€

Stock: 12
Model: HAC-HDW1231TMQ-A-0280B
MPN: HAC-HDW1231TMQ-A-0280B

Dahua Technology

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

Lite Series is suitable for users who requires high quality monitoring products at a reasonable price. It is cost effective and offers high performance, which makes it an ideal choice for residential and small-medium business applications. This series offers an option of a wide range of technologies such as Full-color and Starlight, providing various solutions for different scenarios.

Audio
Signal-to-Noise Ratio (SNR)	65 dB
Audio input channels	1.0 channels
Built-in microphone	Yes
Camera
White balance	Auto, Manual
Minimum illumination	0.002 lx
Camera pan control	Yes
Angle of rotation	360°
Camera tilt control	Yes
Lens viewing angle, horizontal	107°
Lens viewing angle, diagonal	127°
Lens viewing angle, vertical	56°
Tilt angle range	0 - 90°
Camera shutter type	Electronic
Pan range	0 - 360°
Camera shutter speed	1/3 - 1/100000 s
Adjustment shutter speed	Auto/Manual
Image sensor
Number of sensors	1
Optical sensor size	25.4 / 2.8 mm (1 / 2.8")
Progressive scan	Yes
Sensor type	CMOS
Night vision
Number of illumination LEDs	2
Night vision	Yes
Night vision distance	60 m
LED type	IR
Operational conditions
Operating relative humidity (H-H)	0 - 95%
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	0 - 95%
Ports & interfaces
BNC output ports	1
Video
Analog signal format system	PAL
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes	720p, 1080p
Maximum resolution	1920 x 1080 pixels
Total megapixels	2 MP
Gain control type	Auto/Manual
Frame rate	30 fps
Noise reduction	Yes
Noise reduction technology	3D noise reduction
Back Light Compensation (BLC)	Yes
Privacy masking	Yes
Highlight Compensation (HLC)	Yes
Smart IR	Yes
Weight & dimensions
Height	99.1 mm
Weight	420 g
Diameter	12.2 cm
Design
Housing material	Metal, Plastic
Mounting type	Ceiling
International Protection (IP) code	IP67
Form factor	Turret
Product colour	White
Security
Privacy protection	Yes
Mirror	Yes
Lens system
Fixed focal length	2.8 mm
Number of lenses	1
Maximum aperture number	1.6
Identify distance	4.4 m
Packaging data
Package weight	620 g
Performance
Type	CCTV security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Dynamic range	130 dB
Certification	CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Power
DC output voltage	12
Power source type	DC
Power consumption (max)	5.1 W
Storage
Built-in HDD	No

Tags: Security Cameras
