NVR4208-8P-EI

NVR4208-8P-EI
NVR4208-8P-EI
NVR4208-8P-EI
Out Of Stock
NVR4208-8P-EI
NVR4208-8P-EI
NVR4208-8P-EI
NVR4208-8P-EI
350.90€
Ex Tax: 290.00€
  • Stock: Out Of Stock
  • Model: NVR4208-8P-EI
  • MPN: NVR4208-8P-EI
Series Overview

Dahua Lite series NVR is easy to install, cost effective and compatible with a wide variety of third-party devices, providing a great solution for small and medium surveillance systems. It is ideal for home safety, supermarkets, warehouses, educational institutions, and financial institutions.

Face Recognition

Dahua Face Recognition technology extracts the features of captured faces and compares them with that in face database.

Perimeter Protection

Automatically filters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.

SMD Plus

With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.

AI Search

With AI search, operators can search for videos by the attributes of targets and event types, which helps them to quickly and efficiently investigate where and when targets appeared and events took place.

Heat Map by Camera

Dahua heat map technology is used to display the crowd density and people appearance probability. Export and display the crowd status by different colors. Generally, the crowd status is the statistics of people quantity in space and time dimensions.

ANPR by Camera

With deep learning algorithm, Dahua ANPR technology can recognize the number plate information of vehicles in the image with ANPR cameras. Support blocklist/allowlist mode, searching target vehicles from recorded video.

Quick Pick

Dahua Quick Pick technology can enable users to quickly pick up the human/vehicle targets that they are interested in, which facilitates retrieval from SMD events.
Features
Rack capacity 1U
Certification EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Rack mounting Yes
Product colour White
Operational conditions
Operating relative humidity (H-H) 10 - 93%
Storage temperature (T-T) -20 - 60 °C
Operating temperature (T-T) -10 - 55 °C
Ports & interfaces
Ethernet LAN data rates 10,100,1000 Mbit/s
Audio RCA inputs 1
HDMI ports quantity 1
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 8
VGA (D-Sub) output ports 1
HDMI output Yes
Audio RCA outputs 1
USB 2.0 ports quantity 2
Ethernet LAN (RJ-45) ports 1
Networking standards IEEE 802.3af, IEEE 802.3at
Supported network protocols HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
DC-in jack Yes
System requirements
Mobile operating systems supported Android, iOS
Browser supported Chrome; IE9 and later; Firefox
Technical details
Compliance certificates CE, Federal Communications Commission (FCC)
Weight & dimensions
Width 375 mm
Depth 329.3 mm
Height 53 mm
Weight 2.51 kg
Package width 451 mm
Package depth 147 mm
Package height 425 mm
Package weight 3.66 kg
Wireless LAN features
Wi-Fi No
Hard drive
Maximum storage capacity 16 TB
Number of HDDs supported 2
HDD interface SATA
Performance
Alarm input channels 4
Alarm output channels 2
Video recording modes 720p, 960p, 1080p
People counting Yes
Supported resolutions HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Maximum resolution 3840 x 2160 pixels
Video formats supported H.264, H.264+, H.265, H.265+
Input bandwidth 256 Mbit/s
Output bandwidth 256 Mbit/s
Face detection Yes
Audio formats supported G.711 A-law, G.711 μ-law, G.726, PCM
Operating system installed Embedded LINUX
Backup function Yes
Image formats supported MJPEG
Video input channels 8 channels
Multi-screen Yes
Power
Total Power over Ethernet (PoE) budget 72 W
Power consumption (typical) 25.5 W
AC input voltage 100-240 V
AC input frequency 47-63 Hz
Power over Ethernet (PoE) power per port 25.5 W
Power consumption (max) 10 W
