1,340.20€
Ex Tax: 1,107.60€
  • Stock: 33
  • Model: 12TH001HMX
  • UPC: 019815444736
  • JAN: 0198154447366
  • MPN: 12TH001HMX
Performance-Driven, Productivity Perfected

Fueled by Intel® Core™ processor with up to Intel vPro® Enterprise, the ThinkCentre M90q Gen 5 Tiny PC delivers enterprise-grade performance, security, manageability, and reliability — managing businesses of all sizes while boosting productivity, creative output, and digital collaborations with vast memory, storage, and up to WiFi 7.

Workspace Efficiency Redefined

Connect to multiple peripherals via a hub of ports, and enable customization with optional expansion slots such as VGA / DisplayPort / HDMI® / Ethernet (RJ45) / USB-C®, etc. Charge your smartphone readily using the PowerShare USB, even with the PC powered off. Plus, multitask easily with support for up to four independent displays — the sky’s the limit.

Device Convenience Reimagined

With a keyboard shortcut to turn on the desktop, and a quick boot-up process via the Thunder Boot feature, this ThinkCentre PC reflects ease of convenience, making it the perfect choice for modern workspaces. Plus, with Modern Standby, your system remains up-to-date even during sleep mode, and it wakes and connects instantly.

Ultimate PC Security Enabled

Our ThinkShield security encrypts data via the discrete Trusted Platform Module (dTPM), while the self-healing BIOS restores earlier system settings. Secure your PC physically with the Kensington Security Slot™, and choose the Intel vPro® Enterprise platform for multilayer security like Intel® Hardware Shield to block cyberattacks and ransomware.

Effortless Upgrades, Easy Maintenance

Along with a sleek design, the ThinkCentre M90q Gen 5 Tiny desktop is also ready for toolless upgrades, saving IT valuable time. The removable easy-to-clean dust shield assists with upkeep to extend the lifecycle. Plus, an AI-driven fan prevents overheating issues — keeping the system cool and efficient for all-day-long operations.

Future Forward, Future Ready

The M90q Gen 5 uses 85% recycled post-consumer content acrylonitrile butadiene styrene plastics in the chassis. The packaging has 60% post-industry content (PIC), 30% ocean-bound plastic in the thermal shell and bag, and is certified by Forest Stewardship Council® (FSC). Plus, ENERGY STAR® 8.0 and TCO 9.0 ratings minimize energy costs.
Certificates
Certification ErP Lot 3 RoHS compliant TCO Certified 9.0 MIL-STD-810H
Display
Display included No
Operational conditions
Operating relative humidity (H-H) 20 - 80%
Storage temperature (T-T) -40 - 60 °C
Operating temperature (T-T) 5 - 35 °C
Storage relative humidity (H-H) 10 - 90%
Operating altitude 0 - 3048 m
Non-operating altitude 0 - 12192 m
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
DisplayPorts quantity 2
HDMI ports quantity 1
HDMI version 2.1
Ethernet LAN (RJ-45) ports 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4
USB 3.2 Gen 2x2 Type-C ports quantity 1
Combo headphone/mic port Yes
Processor
Performance-core Max Turbo Frequency 5.3 GHz
Performance cores 8
Efficient cores 12
Performance-core base frequency 2.1 GHz
Number of processors installed 1
Efficient-core base frequency 1.5 GHz
Processor base power 65 W
Maximum turbo power 219 W
Processor manufacturer Intel
Processor generation Intel® Core™ i7 (14th gen)
Processor family Intel® Core™ i7
Processor model i7-14700
Efficient-core Max Turbo Frequency 4.2 GHz
Processor boost frequency 5.4 GHz
Processor threads 28
Processor cores 20
Processor cache 33 MB
Processor cache type Smart Cache
Weight & dimensions
Width 179 mm
Depth 182.9 mm
Height 36.5 mm
Weight 1.25 kg
Package width 490 mm
Package depth 128 mm
Package height 250 mm
Package weight 2.85 kg
Design
Product colour Black
Placement supported Horizontal/Vertical
VESA mounting Yes
Volume 1 L
Cable lock slot Yes
Cable lock slot type Kensington
Chassis type Mini PC
Memory
Memory channels Dual-channel
Internal memory 32 GB
Internal memory type DDR5-SDRAM
Memory clock speed 5600 MHz
Memory layout (slots x size) 2 x 16 GB
Memory slots 2x SO-DIMM
Maximum internal memory 64 GB
Network
Ethernet LAN Yes
Ethernet LAN data rates 100,1000,2500 Mbit/s
Wi-Fi Yes
Bluetooth Yes
Cabling technology 10/100/1000Base-T(X)
Wi-Fi standards Wi-Fi 6E (802.11ax)
Top Wi-Fi standard Wi-Fi 6E (802.11ax)
Antenna type 2x2
WLAN controller model Intel Wi-Fi 6E AX211
WLAN controller manufacturer Intel
Bluetooth version 5.3
Packaging content
Mouse included Yes
Mouse connectivity Wired
Keyboard included Yes
Keyboard connectivity Wired
Performance
Product type Mini PC
Trusted Platform Module (TPM) version 2.0
Market positioning Everyday
Motherboard chipset Intel Q670
Audio chip Realtek ALC233
Built-in speaker(s) Yes
Audio system High Definition Audio
Number of speakers 1
Password protection Yes
Password protection type BIOS, HDD, Power on, SSD, Supervisor
Trusted Platform Module (TPM) Yes
Power
Power supply 230 W
Storage
Number of storage drives installed 2
Card reader integrated No
Total storage capacity 1.02 TB
Storage media SSD
Total SSDs capacity 1.02 TB
Number of SSDs installed 2
SSD capacity 512 GB
SSD interface PCI Express 4.0
NVMe Yes
SSD form factor M.2
Optical drive type No
Graphics
On-board graphics card family Intel® UHD Graphics
Discrete graphics card model Not available
On-board graphics card Yes
On-board GPU manufacturer Intel
Discrete graphics card No
On-board graphics card model Intel UHD Graphics 770
Software
Operating system language English, Swedish, Finnish, Danish, Norwegian
Operating system installed Windows 11 Pro
