EON

Name: EON
Brand: CHIEFTEC
SKU: 1401194
Price: 48.96 EUR
Availability: InStock

EON

48.96€

Ex Tax: 40.46€

Stock: 50
Model: ZPU-700S
UPC: 075326307844
JAN: 0753263078445
MPN: ZPU-700S

CHIEFTEC

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

The EON Series offers high quality and 80 PLUS® 230V EU efficiency at highly
competitive pricing, equipped with silent 120mm fans.

The power supplies are fully built from steel, coated in elegant black, and
equipped with extra-long native cables. The EON Series runs quietly and provides
its power with all essential protection and safety features.

Ports & interfaces
EPS power connector (4+4 pin)	Yes
CPU power connector (4+4 pin)	Yes
Motherboard power cable length	65 cm
Peripheral (Molex) power cable length	450,600,750 mm
Motherboard power connector	20+4 pin ATX
SATA power cable length	450,600,750 mm
Number of SATA power connectors	4
PCI Express power connectors (6+2 pin)	2
ATX power connector (20+4 pin)	Yes
Cabling type	Non-Modular
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	86 mm
Weight	1.4 kg
Design
On/off switch	Yes
Fan diameter	12 cm
Product colour	Black
Performance
Power supply unit (PSU) form factor	ATX
Supported motherboard form factors	ATX
80 PLUS certification	80 PLUS
ATX version	2.3
Purpose	PC/Server
Power
Total power	700 W
Maximum input current (@220V)	5.5 A
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (-12V)	4.8 W
Max output current (+3.3V)	20 A
Max output current (+12V1)	53 A
Max output current (+5V)	20 A
Max output current (-12V)	0.4 A
Max output current (+5Vsb)	2.5 A
Power protection features	Surge and inrush, Surge protection, Short circuit
AC input voltage	200 - 240 V
AC input frequency	50 Hz
Input current	5.5 A
Logistics data
Warranty period	2 year(s)

Tags: Power Supply Units
