GPE-700S

Name: GPE-700S
Brand: CHIEFTEC
SKU: 1207546
Price: 53.22 EUR
Availability: InStock

GPE-700S

53.22€

Ex Tax: 43.98€

Stock: 50
Model: GPE-700S
MPN: GPE-700S

CHIEFTEC

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

The name ECO stands for maximum efficiency, ecological values and a new era of power supplies. Compatible with all current standards and certified by TÜV amongst many others and with a fixed voltage of 230V being the European standard, the ECO series is a reliable and efficient companion for modern IT structures which thereby also fulfills all ENERGY STAR 5.0 requirements as stipulated by the EU.

Certificates
Compliance certificates	RoHS
Ports & interfaces
Motherboard power cable length	40 cm
Motherboard power connector	24-pin ATX
Number of SATA power connectors	6
Peripheral (Molex) power connectors (4-pin)	2
EPS power connector (8-pin)	Yes
PCI Express power connectors (6+2 pin)	1
Cabling type	Non-Modular
PCI Express connector	Yes
Technical details
Sustainability certificates	ENERGY STAR
Weight & dimensions
Width	140 mm
Depth	150 mm
Height	86 mm
Design
Cooling type	Active
On/off switch	Yes
Fan diameter	12 cm
Number of fans	1 fan(s)
Product colour	Black
Packaging data
Package type	Box
Performance
Power supply unit (PSU) form factor	PS/2
80 PLUS certification	80 PLUS Bronze
ATX version	2.3
Purpose	PC
Power
Total power	700 W
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	130 W
Combined power (+12V)	630 W
Combined power (+5V)	130 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	22 A
Max output current (+12V1)	52.5 A
Max output current (+5V)	22 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Efficiency	85%
Power protection features	Over voltage, Overload, Short circuit, Under voltage
AC input voltage	230 V
AC input frequency	50 Hz
Input current	6.3 A
Other features
Housing colour	Black
