CASE PSU ATX 750W/GDP-750C CHIEFTEC

Name: CASE PSU ATX 750W/GDP-750C CHIEFTEC
Brand: CHIEFTEC
SKU: 1207558
Price: 71.33 EUR
Availability: InStock

71.33€

Ex Tax: 58.95€

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	8
Peripheral (Molex) power connectors (4-pin)	3
EPS power connector (8-pin)	Yes
PCI Express power connectors (6+2 pin)	4
Floppy drive power connector	1
Cabling type	Semi-Modular
Weight & dimensions
Width	160 mm
Depth	150 mm
Height	87 mm
Design
Fan diameter	14 cm
Number of fans	1 fan(s)
Product colour	Black
Fan location	Top
Performance
Power supply unit (PSU) form factor	PS/2
ATX version	2.3
Purpose	PC
Power
Total power	750 W
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	120 W
Combined power (+12V)	744 W
Combined power (+5V)	120 W
Combined power (+5Vsb)	2.5 W
Max output current (+3.3V)	22 A
Max output current (+12V1)	62 A
Max output current (+5V)	22 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage
AC input voltage	200 - 240 V
AC input frequency	47 - 63 Hz
Logistics data
Harmonized System (HS) code	84733020
Other features
Frequency tolerance	90%

Tags: Power Supply Units
