2 Port HDMI 8K60 Splitter with Audio










2 Port HDMI 8K60 Splitter with Audio
128.79€
Ex Tax: 106.44€
- Stock: 5
- Model: 38534
- UPC: 400288838534
- JAN: 4002888385343
- MPN: 38534
The Lindy 2 Port HDMI® 8K60 Splitter with Audio is a multi-function solution for distributing high quality HDMI® signals across 2 displays simultaneously from one source device, while extracting digital or analogue audio separately.
With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
Features | |
Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
Easy to install | Yes |
Data transfer rate | 48 Gbit/s |
Maximum resolution | 7680 x 4320 pixels |
Housing material | Metal |
LED indicators | Yes |
Maximum refresh rate | 60 Hz |
Product colour | Black |
HD type | 8K Ultra HD |
HDCP version | 2.3 |
Colour depth | 8 bit |
HDCP | Yes |
Operational conditions | |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 20 - 90% |
Ports & interfaces | |
Video port type | HDMI |
Video ports quantity | 2 |
HDMI version | 2.1 |
Headphone out | Yes |
Headphone connectivity | 3.5 mm |
Video out | 2x HDMI |
Digital audio optical out | 1 |
DC-in jack | Yes |
Technical details | |
Warranty period | 2 year(s) |
Connector 1 | 2 x HDMI Type A |
Connector 2 | HDMI Type A |
Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
Weight & dimensions | |
Width | 145 mm |
Depth | 17 mm |
Height | 68 mm |
Weight | 325 g |
Packaging content | |
Manual | Yes |
Included power plug types | AU, EU, UK |
Cables included | Power |
AC adapter included | Yes |
Packaging data | |
Package width | 200 mm |
Package depth | 70 mm |
Package height | 115 mm |
Package weight | 458 g |
Quantity per pack | 1 pc(s) |
Package type | Box |
Power | |
AC input voltage | 5 V |
Input current | 2 A |
