Power Supply|GIGABYTE|GP-P550SS ICE|550 Watts|Efficiency 80 PLUS SILVER|PFC Active|MTBF 100000 hours|GP-P550SSICE

45.33€

Ex Tax: 37.46€

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Ports & interfaces
CPU power connector (4+4 pin)	Yes
Motherboard power cable length	60 cm
Peripheral (Molex) power cable length	500 mm
Motherboard power connector	20+4 pin ATX
SATA power cable length	500 mm
Number of SATA power connectors	5
CPU power cable length	60 cm
Peripheral (Molex) power connectors (4-pin)	3
PCI Express power cable length	50 cm
PCI Express power connectors (6+2 pin)	2
ATX power connector (20+4 pin)	Yes
Floppy drive power connector	1
Cabling type	Non-Modular
Floppy disk drive connector	Yes
PCI Express connector	Yes
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	86 mm
Design
Cooling type	Active
On/off switch	Yes
Fan diameter	12 cm
Number of fans	1 fan(s)
Product colour	White
Fan location	Top
Performance
Power supply unit (PSU) form factor	ATX
Bearing technology	HDB
80 PLUS certification	80 PLUS Bronze
ATX version	3.0
Mean time between failures (MTBF)	100000 h
Purpose	PC
Power
Total power	550 W
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	549.6 W
Max output current (+12V)	45.8 A
Combined power (+5V)	200 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Hold time	16 ms
Max output current (+5Vsb)	3 A
Efficiency	90%
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
AC input frequency	50/60 Hz
Input current	6.3 A
Logistics data
Harmonized System (HS) code	84733020
