CHS4206-4ET-90

Name: CHS4206-4ET-90
Brand: Dahua Technology
SKU: 1462939
Price: 63.08 EUR
Availability: InStock

CHS4206-4ET-90

63.08€

Ex Tax: 52.13€

Stock: 2
Model: CHS4206-4ET-90
MPN: CHS4206-4ET-90

Dahua Technology

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Specifications

Certificates
Compliance certificates	CE
Data transmission
Forwarding rate	3.57 Mpps
Switching capacity	4.8 Gbit/s
MAC address table	8000 entries
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	4 MB
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-30 - 65 °C
Storage relative humidity (H-H)	5 - 95%
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	4
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	4
Power connector	DC-in jack
SFP module slots quantity	2
Weight & dimensions
Width	110.4 mm
Depth	154.3 mm
Height	30 mm
Weight	320 g
Design
Housing material	Iron
Reset button	Yes
IK code	IK06
International Protection (IP) code	IP30
Rack mounting	No
DIN rail mounting	Yes
Form factor	Desktop
Product colour	Blue
Management features
Switch type	Managed
Switch layer	L2
Cloud-managed	Yes
Web-based management	Yes
Multicast features
Multicast support	Yes
Network
Networking standards	IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
10G support	No
Flow control support	Yes
Broadcast storm control	Yes
Port mirroring	Yes
VLAN support	Yes
Number of VLANs	32
Security
DHCP features	DHCP client
Loop protection	Yes
Packaging content
Manual	Yes
Cables included	AC
Quick start guide	Yes
Packaging data
Package width	239 mm
Package depth	266 mm
Package height	77 mm
Package weight	870 g
Terminal block included	Yes
Package type	Box
Performance
Mean time between failures (MTBF)	1852444.63 h
Power
Power source	DC/PoE
Power supply included	Yes
DC input voltage	48 - 57 V
Power supply location	External
Power consumption (max)	92.7 W
Input current	2 – 1.69
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	4
Total Power over Ethernet (PoE) budget	90 W

Tags: Network Switches
