M4250-10G2XF-PoE+

Name: M4250-10G2XF-PoE+
Brand: NETGEAR
Price: 1026.85 EUR
Availability: InStock

M4250-10G2XF-PoE+

1,026.85€

Ex Tax: 848.64€

Stock: 3
Model: GSM4212PX-100EUS
Weight: 4.64kg
Dimensions: 535.00 x 0.00 x 120.00
UPC: 060644914958
JAN: 0606449149586
MPN: GSM4212PX-100EUS

NETGEAR

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description
Specifications

Switching engineered for 1G AV over IP with PoE+, Ultra90 PoE++ and rear-facing ports ensuring a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante etc. as well as audio/video/control mixed profiles. When multiple switches, NETGEAR IGMP Plus brings automation for you to just connect them together.

M4250 Support for Audio Video Bridging (AVB)
One of the many features designed into the new M4250 product line is full support for Audio Video Bridging (AVB), an industry standard for transporting content over a network. AVB is used most often when very low latency is required such as in live performances when lip sync is critical. All of the AV Line M4250 switches can be optionally licensed for AVB support.

Data transmission
Switching capacity	60 Gbit/s
MAC address table	16000 entries
Store-and-forward	Yes
Throughput	44.64 Mpps
Latency (1 Gbps)	2.14 µs
Number of queues	8
Jumbo frames support	Yes
Jumbo frames	12000
Packet buffer memory	16 MB
Operational conditions
Operating relative humidity (H-H)	0 - 90%
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	1046.05 BTU/h
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	10
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	2
Weight & dimensions
Width	440 mm
Depth	200 mm
Height	43.2 mm
Weight	2.96 kg
Design
Rack mounting	Yes
Form factor	1U
Product colour	Black
LED indicators	PoE, Power, Status
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Multicast features
Multicast support	Yes
IPv4 multicast entries	2000
IPv6 multicast entries	2000
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
10G support	No
Full duplex	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Virtual LAN features	MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Number of VLANs	4093
Security
DHCP features	DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Access Control List (ACL)	Yes
Authentication	MAC-based authentication
Authentication type	RADIUS
IGMP snooping	Yes
SSH/SSL support	Yes
Loop protection	Yes
BPDU filtering/protection	Yes
Performance
Noise level	39.22 dB
Processor model	ARM Cortex-A9
Mean time between failures (MTBF)	947871 h
Built-in processor	Yes
Internal memory	2048 MB
Processor frequency	1250 MHz
Power
Power consumption (typical)	306.4 W
Logistics data
Harmonized System (HS) code	85176990
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Total Power over Ethernet (PoE) budget	240 W
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
